This page is sizing. If you're looking for geometry descriptions click here.
This year, we've decided to publish our stock frame sizes, but we still want to know that you are not limited to the sizes below. For other manufacturers, custom frames are either not done or are few and far between....not at Rodriguez. For our customers, sizing is unlimited and we don't want you to think that you must try to fit into one of our stock geometries. As a custom builder for years now, we approach sizing differently than just about all other bicycle companies. We want your bike to be just your size. So, if you don't see your size below, or, you don't know your size and would like help determining it, contact us today.
At Rodriguez, we offer 20 stock sizes as well as full custom sizing (for just $295 extra). Although we can fit most of our customers easily on one or more of our stock sizes, we still end up building about half of our bikes full custom for one reason or another.
Rodriguez L Sizes | |||||||
L Sizes | A. | B. | C. | D. | E. | F. | G. |
1L | 48.6 | 34.7 | 48.7 | 41 | 67.5 | 74° | Small |
2L | 50 | 35 | 49 | 42.5 | 69.7 | 73° | Small |
3L | 51.3 | 34.9 | 52.6 | 46 | 72.1 | 73° | Small |
4L | 52.5 | 36.1 | 53.5 | 49.4 | 75.4 | 73° | Both |
5L | 54.1 | 37.6 | 54.5 | 51.6 | 77.1 | 73° | Large |
6L | 55 | 38.1 | 55.2 | 53.8 | 78.5 | 73° | Large |
7L | 56.2 | 38.5 | 56.8 | 56.2 | 80.5 | 73° | Large |
8L | 57.4 | 39.4 | 58.6 | 58.3 | 82.3 | 73° | Large |
9L | 58.1 | 39.2 | 61.7 | 61 | 85.2 | 73° | Large |
10L | 59.3 | 39.7 | 64.2 | 63.7 | 87.6 | 73° | Large |
Rodriguez S Sizes | |||||||
S Sizes | A. | B. | C. | D. | E. | F. | G. |
1S | 47.7 | 31.8 | 51.6 | 43.7 | 71.2 | 74° | Small |
2S | 49 | 32 | 53 | 45.4 | 72.7 | 73° | Small |
3S | 50 | 32.6 | 54.5 | 47.2 | 74.6 | 73° | Small |
4S | 50.9 | 33.1 | 56.5 | 49.4 | 76.6 | 73° | Small |
5S | 53.9 | 35.4 | 58.7 | 51.6 | 78.7 | 73° | Large |
6S | 54.4 | 35.5 | 60.5 | 53.8 | 80.7 | 73° | Large |
7S | 55 | 35.9 | 60.9 | 56.2 | 82 | 73° | Large |
8S | 55.8 | 36.5 | 62 | 58.3 | 83.6 | 73° | Large |
9S | 56.2 | 36.6 | 63.7 | 61 | 85.9 | 73° | Large |
10S | 57.5 | 36.9 | 66.5 | 63.7 | 88.5 | 73° | Large |
